Rotunda

Patient Transfer Aid

The risk of back pain and other musculoskeletal disorders (MSDs) is a very real issue for carers and nurses.

Consider the amount of physical effort that is required and the awkward positions that a nurse or carer may have to get into when transferring a patient from sitting to standing to sitting. The use of a Rotunda patient transfer aid can remove the need for manual handling and lower the risk of injury to the carer, whilst providing a safer, more dignified and comfortable transfer solution for the patient.


Robust, strong and built to last

Handmade in Haverhill since 1987, following consultation with our clients the original Rotunda has been engineered and adapted and is now the leading patient transfer aid on the market.

Thousands are used in NHS and private hospitals, care homes and residences up and down the country.

Manufactured from premium steel it is robust, strong and built to last by our team of craftsmen.

A safer, more comfortable and dignified experience for the patient

The sturdy frame instils confidence in the patient as they make the transition between a bed, seat, commode or wheelchair. The wide turntable provides a stable and safe area that the patient can confidently step on to while the transfer takes place. The Rotunda rotates between five different positions with a locking device to ensure patient safety.

The Patient’s risk and fear of falling is diminished with the high visibility features for hand and feet placement. The curved support frame provides added security and peace of mind as the patient is actively involved in the transfer, which will improve their circulation and they can enjoy a sense of independence rather than just being passively lifted from one place to another.

A simplified, less risky solution for the carer

To the uninitiated moving a person with limited mobility from a bed to a wheelchair may seem like a very simple process. To the carer the risk of back injury in carrying out this task repeatedly throughout the day is a very real occupational hazard. Fortunately using the Rotunda patient transfer aid greatly diminishes this risk as it eliminates the need to lift the patient.

In the majority of cases, provided the appropriate risk assessment has been undertaken, a single carer can manage the transfer when using the Rotunda, freeing up resources that can be utilised in other areas. Large wheels make the Rotunda very easy to manoeuvre over all types of floor coverings including carpet.


How the Rotunda works

An animated guide

Patient transfer is simple and easy using the Rotunda transfer aid.


View Instructions for use

VAT exempt?

For more information about  VAT exemption, please visit our FAQ's

If you would like to speak with us, please call 01440 702811


Standard Frame Rotunda with knee support
(RS1 + RAKS1)

Standard frame model

Available in White

The standard frame Rotunda is designed for users who can weight bear.

For safety and comfort we recommend the use of the Knee Support accessory - available separately or at the time of purchase.

  • Width between Handles: 420mm
  • Overall Height: 1020mm
  • Overall Width: 660mm (will pass through standard door frame)
  • Overall Depth: 618mm
  • Handle Height: (from floor) 780mmTurntable Diameter: 457mm
  • Unit weight: 13kg (29lb)

All Rotundas have a maximum turntable load of 250kg (39 stones)

Get a quote

Bariatric Frame Rotunda with knee support
(RB1 + RAKS1)

Wide frame model for bariatric care

Available in White

The bariatric frame Rotunda is designed for users who can weight bear.

For safety and comfort we recommend the use of the Knee Support accessory - available separately or at the time of purchase.

  • Width between handles: 520mm
  • Overall Height: 1020mm
  • Overall Width: 660mm
  • Overall Depth: 618mm
  • Handle Height: (from floor) 780mm
  • Turntable Diameter: 457mm
  • Unit weight: 13kg (29lb)

All Rotundas have a maximum turntable load of 250kg (39 stones)

Get a quote

Height Adjustable Frame Rotunda with knee support
(RSHA1 + RAKS1)

Available in White

The standard height adjustable frame Rotunda is designed for users who can weight bear.

For safety and comfort we recommend the use of the Knee Support accessory - available separately or at the time of purchase.

  • Overall Height: 960-1170mm
  • Width between handles: 420mm
  • Overall Width: 660mm (will pass through standard door frame)
  • Overall Depth: 618mm
  • Handle Height: (from floor) 720-950mm
  • Turntable Diameter: 457mm
  • Unit weight: 13kg (29lb)

All Rotundas have a maximum turntable load of 250kg (39 stones)

Get a quote

Accessories

Complement your Rotunda Patient Transfer Platform with our range of accessories


Knee Support  (RAKS1)

The Rotunda Knee Support fits all models.

The padded knee support can be added to all Rotundas to provide extra safety and comfort for the patient. The knee support is ideal for more infirm patients.

The Knee Support can be ordered with the Rotunda at time of purchase or retro-fitted onto an existing frame.

Get a quote

Arm Supports  (RAAS1)

Rotunda Arm Supports for all models

The arm supports are designed for use by patients who have a weakened grip. They can rest their arms in the supports and hold the vertical handles.

Arm supports can be ordered with the Rotunda or retro-fitted onto an existing frame.

Get a quote

Raising Blocks
(RARB3) or (RARB5)

Rotunda Raising Blocks for all models

Raising Blocks are Diameter: 400mm (15 ¾ inches) available in two heights 76mm (3") and 127mm (5")

By adding raising blocks to the turntable base on the Rotunda it can be used to accommodate patients of smaller stature.

If required both raising blocks can be used together to give a maximum overall height increase of 203mm (8").

Rotunda Raising Blocks can be ordered with the Rotunda or retro-fitted onto an existing frame.

3" (RARB3) Get a quote
5" (RARB5) Get a quote
